High Temperature Thermocouple Assemblies
Operating Temperatures Up to 4200˚F (2315˚C)
for Vacuum Furnace
Thermocouple Assemblies with Terminal Head & Direct Mount
Terminal Head Assembly
Conax Buffalo provides high temperature assemblies with
T5, T8 and T11 termination heads in aluminum, stainless
steel or cast iron to meet application needs. T5 termination
heads meet NEMA 4 requirements providing protection
against windblown dust and rain, splashing water, hosedirected
water and external ice formation.
(See page 11 for details on termination heads.)
The sheath is affixed to the terminal head using a Conax
Buffalo packing gland Type PG4 with sealant. Terminal heads
with terminal blocks and gasket seal are rated to 275˚ F
(135˚ C).
The direct mount style features a B Cap with .50 NPT mounting.
Notes:
• .125" diameter sheath is available with 30 gauge wire only.
• Alumina sheath is not available in .125" diameter.
• Molybdenum, Tantalum and Tungsten are not available in .375" diameter.
• Lava sealant not recommended for high vacuum.
